Centrifuge for static, dynamic or vacuum application of a product to various metal, plastic or other parts

Centrifuge | Separation solid-liquid | Group: IMP



  Characteristics

  • Simplicity of application principle.
  • Dripping eliminated.
  • Touch-dry parts (depending on product).
  • Optimum accessibility for cleaning and maintenance.

  Performance

  • Controlled consumption of application product.
  • Deposited on all surfaces.
  • Fully automatic recycling.
  • Assured reproducibility.
  • Possibility of vapour management

  Functionability

  • Recycling of application product.
  • Guaranteed clean, unpolluted deposit.
  • No aerosols.



  Download brochure as PDF

  Submit request

Technical data filters

Type Reel ⌀ (mm) Reelhight (mm) Useful volume (L) max. loading (kg) Filter surface (m2) max. Rotation speed max. G-number
SA 40 KC IMP 300 180 8 25 170 1.000 168
SA 50 KC IMP 475 280 30 60 418 1.000 266
SC 70 KC IMP 645 330 50 100 669 900 292
SC 85 KC IMP 790 380 90 180 943 750 248



Technical data decanter

Type Reel ⌀ (mm) Reelhight (mm) Useful volume (L) max. loading (kg) max. Rotation speed max. G-number
RC 50 KC IMP 475 280 30 60 1.000 266
